X-RAY IMAGE IDENTIFICATION AND INTERPRETATION
Product Code: P-211-E
Technical Manuals, Articles, Books and Publications Description:
Three-ring binder with 8 inch X 10 inch photos facing each other. Components are in color; radiographs are in black and white. All photos are sleeved, and descriptions are provided.
NOTE: Radiographic images were made using a portable X-Ray unit on Polaroid TPX transparency film. Dense items were X-Rayed at two different pulse levels and both levels are shown. Pulse levels are indicated, for reference, on all radiographs.
